Trommel Screen

Short Description:

Drum screen provide a simple,efficient and economical solution to upgrade a wide rang of material and optimize the subsequent process steps of recovery.This method of screening helps to reduce operating and investment cost and to increase product quality,while allowing rapid and large volume processing.

CONTACT NOW

Product Detail

Product Tags

Product Pictures

Product Parameters

Model	Capacity	Power	Diameter	Length	Screen size	Dimension	Weight
LZGT0610	5-10 t/h	2.2 kw	600 mm	1000 mm	3～50 mm(can use double or three layers, customized)	2520/1020/1860 mm	1600 kg
LZGT1015	10-20 t/h	4.0 kw	1000 mm	1500 mm		3060/1400/2145 mm	2200 kg
LZGT1020	20-25 t/h	5.5 kw	1000 mm	2000 mm		3460/1400/2145 mm	2800 kg
LZGT1225	25-35 t/h	7.5 kw	1200 mm	2500 mm		4146/1600/2680 mm	4200 kg
LZGT1530	35-50 t/h	11 kw	1500 mm	3000 mm		4460/1900/2820 mm	5100 kg
LZGT1545	50-70 t/h	15 kw	1500 mm	4500 mm		5960/1900/3080 mm	6000 kg
LZGT1848	70-90 t/h	22 kw	1800 mm	4800 mm		6500/2300/4000 mm	7500 kg
LZGT2055	90-120 t/h	30 kw	2000 mm	5500 mm		7500/2500/4000 mm	8600 kg
